RL78/G23 Lighting Communication Master Evaluation Board for Intelligent Lighting System

Overview

The RL78/G23 Lighting Communication Master Evaluation Board from Renesas is designed to control evaluation boards using various lighting communication standards. It supports DALI, DMX512, and infrared communication protocols, making it suitable for DALI multi-master setups and different DALI test standards. The board includes a Pmod™ interface connector for linking sensors and other devices and features a capacitive touch key sensor for touch-based operation.

See lab in action

Capabilities

Demonstrate the implementation and functionality of the DALI Communication protocol.
Exhibit DALI GUI applications and various control methods.
Analyze output waveforms for accuracy and consistency.
Provide real-time bus monitoring for DALI Communication protocol.
Offer a custom GUI for quick access to the DALI app, bus monitoring view, and command log.

Features

Evaluate the connected board using a real power supply setup.
Enable live control through the DALI GUI application.
Assess different light control methods with real-time feedback.
Monitor output waveforms under various lighting configurations.
Evaluation of the Intelligent Lighting System board via both command line and GUI.
